Java 다익스트라 알고리즘(Dijkstra Algorithm)에 대해
Java

Java 다익스트라 알고리즘(Dijkstra Algorithm)에 대해

2020. 9. 8. 16:06

다익스트라 알고리즘은 그래프에서 출발점에서 목표점 까지의 최단거리를 구할 때 사용하는 알고리즘이다.



이 때의 그래프의 가중치는 양수여야만 한다. 음수인 경우에는 벨만 포드 알고리즘을 사용해야한다.



동작순서는 다음과 같다.



1. 방문하지 않은 정점 중에서 그 거리가 최소인 점 x을 선택한다.

2. x를 방문 처리한다.

3. x와 연결된 정점들을 검사한다.

4. x와 연결된 정점들까지의 거리가 x를 거쳐 그 점까지의 거리와 비교해서 더 크다면 후자를 전자에 삽입한다.

5. 1~4 반복



이미지 출처 : https://manducku.tistory.com/29

다음과 같이 진행된다.



구현코드는 다음과 같다.

동작원리를 외워두는 것이 좋다.

특정 문제에서는 간선의 방향성이 주어지기도 하고, 갈 수 없는 점이 나오기도 하기 때문이다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
class test{
    static int v;
    static int e;
    static final int inf=1000000;
    public static void main(String[] args) throws IOException {
        Scanner sc = new Scanner(System.in);
        v = sc.nextInt();
        e = sc.nextInt();
        int[][] ad = new int[v+1][v+1];
        int[] dist = new int[v+1];
        boolean[] visit = new boolean[v+1];
        int start = sc.nextInt();

        for (int i = 0; i < e; i++) {
            int a = sc.nextInt();
            int b = sc.nextInt();
            int c = sc.nextInt();
            ad[a][b] = c;
        }
        for (int i = 1; i <= v; i++)
            dist[i]=inf;

        solution(start, dist, ad, visit);
    }

    public static void solution(int start, int[] dist, int[][] ad, boolean[] visit) {
        dist[start] = 0;
        String s="";

        for (int i = 0; i < v; i++) {
            int min = inf + 1;
            int idx = -1;

            for (int j = 1; j <= v; j++) {
                if (!visit[j] && min > dist[j]) {
                    min = dist[j];
                    idx = j;
                }
            }
            visit[idx] = true;
            s+=idx+" ";
            for (int j = 1; j <= v; j++) {
                if (ad[idx][j] != 0 && dist[j] > dist[idx] + ad[idx][j]) {
                    dist[j] = dist[idx] + ad[idx][j];
                }
            }
        }
        for (int i = 1; i <=v; i++) {
            if(dist[i]==inf) System.out.println("INF");
            else System.out.println(dist[i]);
        }
    }
}
Colored by Color Scripter
cs

우선순위 큐를 사용하여 구현하면 다음과 같다





1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
import java.util.*;


class Element implements Comparable<Element>{
    int idx;
    int distance;

    Element(int idx, int distance){
        this.idx = idx;
        this.distance = distance;
    }

    @Override
    public int compareTo(Element o) {
        return this.distance - o.distance;
    }
}



public class test {

    static boolean[] visit;
    static int[] dist;
    static int[][] ad;
    static int v, e;
    static final int inf = 100000;


    public static void dijkstra(int start){
        PriorityQueue<Element> que = new PriorityQueue<>();
        dist[start] = 0;
        que.offer(new Element(start, dist[start]));

        while(!que.isEmpty()){
            Element tmp = que.poll();
            int distance = tmp.distance;
            int idx = tmp.idx;

            if(distance > dist[idx])
                continue;

            for(int i = 1; i <= v; i++){
                if(ad[idx][i] != 0 && dist[i] > dist[idx] + ad[idx][i]){
                    dist[i] = dist[idx] + ad[idx][i];
                    que.add(new Element(i, dist[i]));
                }
            }

        }
        System.out.println();
        for(int i =1 ; i <= v; i++){
            System.out.print(dist[i]+" ");
        }
    }

    public static void main(String[] args){
        Scanner sc = new Scanner(System.in);

        v = sc.nextInt();
        e = sc.nextInt();

        visit = new boolean[v+1];
        dist = new int[v+1];
        ad = new int[v+1][v+1];


        for(int i = 0; i <= v; i++){
            dist[i] = inf;
        }


        for(int i = 0; i < e; i++){
            int a = sc.nextInt();
            int b = sc.nextInt();
            int c = sc.nextInt();

            ad[a][b] = c;
            ad[b][a] = c;
        }
        dijkstra(1);
    }
}


Colored by Color Scripter
cs
